Micro dynamique SHURE SM 58

Type

Dynamic (moving coil)

Frequency Response

50 to 15,000 Hz

 View Larger

Polar Pattern

Unidirectional (cardioid), rotationally symmetrical about microphone axis, uniform with frequency

Sensitivity (at 1,000 Hz Open Circuit Voltage)

-54.5 dBV/Pa (1.85 mV)

1 Pa = 94 dB SPL

Impedance

Rated impedance is 150 ohms (300 ohms actual) for connection to microphone inputs rated low impedance

Polarity

Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3

Connector

Three-pin professional audio connector (male XLR type)

Case

Dark gray, enamel-painted, die cast metal; matte-finished, silver, spherical steel mesh grille

Overall Dimensions

See User Guide

Net Weight

298 grams (10
