Type
Condenser (electret bias)
Frequency Response
50 to 17,000 Hz
Output Impedance
1800 ohms
Sensitivity (1 Pa = 94 dB SPL)
WL183: -40.0 dBV/Pa
WL184: -44.5 dBV/Pa
WL185: -45.5 dBV/Pa
Maximum Sound Pressure Level
WL183: 125.0 dB SPL
WL184: 129.5 dB SPL
WL185: 130.5 dB SPL
Output Noise (A-weighted)
WL183: 22.5 dB SPL
WL184: 27.0 dB SPL
WL185: 28.0 dB SPL
Dynamic Range
102.5 dB
Polarity
Positive pressure on diaphragm produces positive voltage on pins 3 and 4 relative to pin 1.
Power Requirements
Regulated nominal +5 Vdc (1.5 Vdc to 10 Vdc) provided at microphone connector pin 2 relative to pin 1 of a Shure wireless microphone transmitter.
